You can use the Library Manager to select or update the BSP and firmware libraries used in this application. To work with a different supported kit later, use the Library Manager to choose the BSP for the supported kit. When you select a supported kit, the example is reconfigured automatically to work with the kit. Pick a kit supported by the code example from the list shown in the Project Creator - Choose Board Support Package (BSP) dialog. Using the code exampleĬreate the project and open it using one of the following: In Eclipse IDE for ModusToolbox™ softwareĬlick the New Application link in the Quick Panel (or, use File > New > ModusToolbox Application). This example requires no additional software or tools. Pin connections to the SPI slave kit Development kitĬonnect the master's MOSI to the slave's MOSI, MISO to MISO, SCLK to SCLK, and CS to CS. The pin assignments for the master and slave devices for the supported kits are listed in Table 1. Use jumper wires to establish a connection between the master and the slave. See the kit user guide to ensure that the board is configured correctly. This example uses the board's default configuration. XMC4800 relax EtherCAT kit ( KIT_XMC48_RELAX_ECAT_V1).XMC4700 relax kit ( KIT_XMC47_RELAX_V1).

XMC4500 relax kit ( KIT_XMC45_RELAX_V1).

XMC4400 Platform2Go kit ( KIT_XMC_PLT2GO_XMC4400).

XMC4300 relax EtherCAT kit ( KIT_XMC43_RELAX_ECAT_V1).

XMC4200 Platform2Go kit ( KIT_XMC_PLT2GO_XMC4200).

XMC1400 boot kit ( KIT_XMC14_BOOT_001) - Default value of TARGET.

GNU Arm® Embedded Compiler v10.3.1 ( GCC_ARM) - Default value of TOOLCHAIN.

Supported toolchains (make variable 'TOOLCHAIN')

Associated parts: All XMC™ 4000 MCU parts.

The successful completion of transfer is indicated by the toggling of an LED on the board. This code example demonstrates the transfer of three bytes of data using the SPI master in XMC™ MCU.
